Overview
MicroLink is an aviation-grade, Beyond Visual Line Of Sight (BVLOS), miniature data link radio specifically designed for long range Unmanned Aircraft System (UAS) Command & Control (C2) data links. It's the ideal choice for applications sensitive to size, weight, and power demands,MicroLink operates in the 902-928 MHz ISM band rather than a dedicated aviation band,making FAA permission-to-transmit unnecessary. Annoying radio frequency interference ismitigated, thanks to a robust dual radio architecture enhanced with spread spectrum(frequency hopping) technology.Parameters
| Specification | Value |
| Band | 902-928MHz ISM Band |
| Architecture | Dual Diversity Radios |
| Transmit Power | 1W (4W EIRP) |
| Bandwidth | 200kHz |
| Receiver Sensitivity | |
| User Receiver | -118dBm |
| Control Receiver | -121dBm |
| Doppler Capture Range | ±16kHz |
